NEW-ERA STEEL TUBE TECHNOLOGY CO.,LTD

NEW-ERA STEEL TUBE HOLDING NINGBO PIPEWAY TRADE CO.,LTD

Verified Supplier

7 Years

Home > Stainless Steel Tubes >

Boiler TP304 Mirror Polished Stainless Steel Tubing

    Buy cheap Boiler TP304 Mirror Polished Stainless Steel Tubing from wholesalers

    Buy cheap Boiler TP304 Mirror Polished Stainless Steel Tubing from wholesalers
    • Buy cheap Boiler TP304 Mirror Polished Stainless Steel Tubing from wholesalers
    • Buy cheap Boiler TP304 Mirror Polished Stainless Steel Tubing from wholesalers

    Boiler TP304 Mirror Polished Stainless Steel Tubing

    Ask Lasest Price
    Brand Name : New-Era
    Model Number : ASTM A312 ASME SA312
    Certification : ISO9001, ISO14001, TS16949
    Price : Negotiation
    Payment Terms : T/T
    Supply Ability : 1500tons per month
    Delivery Time : 35-45days
    • Product Details
    • Company Profile

    Boiler TP304 Mirror Polished Stainless Steel Tubing

    ASTM SA-312/312M 304L/304 Stainless Steel Tube TP304 stainless steel pipes

    Standard: ASTM269, ASTMA213, SA-312/312M, DIN17456. DIN17458, EN10216-5,
    JIS 3459 JIS G3463, GB/T14976-2002,
    1. Material Grade: 304, 304L, 316, 316L, 310S, 430.
    2. Finish: NO. 1, NO. 4, BA, 2B, mirror polised
    3. O. D range: (6.35mm-168mm)1/4inch, 3/8inch, 1/2inch-8inch
    4. Wall thickness: (0.2mm-30mm). 028inch, . 0079inch, . 049inch, . 065inch, 1.2inch
    5. Surface treatment: AP(Annealed & Pickled) or according to customer requirement.
    6. Appication: Chemical industry, chemical fertilizer production, and petrochemical industry, natural gas industry, environmental protection, pharmaceutical chemical, food machinery, water supply, architecture and boiler heat exchangers.
    7. Sample: Avaliable according to customer requirement.
    8. Delivery: 7- 20 days
    9) Inspection: ISO 9001-2000, PED 97/23/EC, ASME, DNV, TUV
    10) Applications: Processing plant for sulphuric, phosphoric and acetic acids fluid and gas transportation; Structure and Machining; Pulp and paper processing; Components in gas scrubbing plants; Seawater cooling equipment; Oil refinery components;
    11) Packing: Seaworthy wooden cases/plywood box/steel framed cases/ simple packaging


    GradeChemical Composition % Max ASTM A240/240M-05 ISO 9445-2002
    CCrNiMnPSMoSiCuNOther
    301≤0.1516.00-18.006.00-8.00≤2.00≤0.065≤0.030-≤1.00---
    302≤0.1517.00-19.008.00-10.00≤2.00≤0.035≤0.030-≤1.00---
    303≤0.1517.00-19.008.00-10.00≤2.00≤0.20≤0.0301)≤1.00---
    303se≤0.1517.00-19.008.00-10.00≤2.00≤0.20≤0.030-≤1.00--Se≥0.15
    304≤0.0717.00-19.008.00-10.00≤2.00≤0.035≤0.030-≤1.00---
    304L≤0.03018.00-20.008.00-10.00≤2.00≤0.035≤0.030-≤1.00---
    304N1≤0.0818.00-20.007.00-10.50≤2.00≤0.035≤0.030-≤1.00-0.10-0.25
    304N2≤0.0818.00-20.007.50-10.50≤2.00≤0.035≤0.030-≤1.00-0.15-0.30Nb≤0.15
    304LN≤0.03017.00-19.008.50-11.50≤2.00≤0.035≤0.030-≤1.00-0.12-0.22-
    305≤0.1217.00-19.0010.50-13.00≤2.00≤0.035≤0.030-≤1.00---
    309S≤0.0822.00-24.0012.00-15.00≤2.00≤0.035≤0.030-≤1.00---
    310S≤0.0824.00-26.0019.00-22.00≤2.00≤0.035≤0.030-≤1.00---
    316≤0.0816.00-18.5010.00-14.00≤2.00≤0.035≤0.0302.00-3.00≤1.00---
    ≤0.1216.00-19.0011.00-14.00≤2.00≤0.035≤0.0301.80-2.50≤1.00--Ti5(C%-0.02)~0.08
    ≤0.0816.00-19.0011.00-14.00≤2.00≤0.035≤0.0301.80-2.50≤1.00--Ti5*C%-0.70
    316L≤0.03016.00-18.0012.00-15.00≤2.00≤0.035≤0.0302.00-3.00≤1.00---
    316N≤0.0816.00-18.0010.00-14.00≤2.00≤0.035≤0.0302.00-3.00≤1.00-0.10-0.22-
    316N≤0.03016.00-18.5010.50-14.50≤2.00≤0.035≤0.0302.00-3.00≤1.00-0.12-0.22-
    316J1≤0.0817.00-19.0010.00-14.50≤2.00≤0.035≤0.0301.20-2.75≤1.001.00-2.50--
    316J1L≤0.03017.00-19.0012.00-16.00≤2.00≤0.035≤0.0301.20-2.75≤1.001.00-2.50--
    317≤0.1218.00-20.0011.00-15.00≤2.00≤0.035≤0.0303.00-4.00≤1.00---
    317L≤0.0818.00-20.0011.00-15.00≤2.00≤0.035≤0.0303.00-4.00≤1.00---
    ≤0.1216.00-19.0011.00-14.00≤2.00≤0.035≤0.0302.50-3.50≤1.00--Ti5(C%-0.02)~0.08
    ≤0.0816.00-19.0011.00-14.00≤2.00≤0.035≤0.0302.50-3.50≤1.00--Ti5*C%-0.70
    317J1≤0.04016.00-19.0015.00-17.00≤2.00≤0.035≤0.0304.00-6.00≤1.00---
    321≤0.1217.00-19.008.00-11.00≤2.00≤0.035≤0.030-≤1.00--Ti5(C%-0.02)~0.08
    ≤0.0817.00-19.009.00-12.00≤2.00≤0.035≤0.030-≤1.00--Ti≥5*C%
    347≤0.0817.00-19.009.00-13.00≤2.00≤0.035≤0.030-≤1.00--Nb≥10*C%
    XM7≤0.0817.00-19.008.50-10.50≤2.00≤0.035≤0.030-≤1.003.00-4.00--
    XM15J1≤0.0815.00-20.0011.50-15.00≤2.00≤0.035≤0.030-3.00-5.00--2)
    329J1≤0.0823.00-28.003.00-6.00≤1.50≤0.035≤0.0301.00-3.00≤1.00--2)
    0.10-0.1817.50-19.5010.--120..≤0.80≤0.035≤0.030-3.40-4.00--Al 0.10-0.

    Products pictures:


    We are the professional duplex stainless steel pipe supplier and super duplex stainless steel pipe manufacturer in China,

    providing high-quality duplex stainless steel pipes and super duplex tubing.

    Tags:304L stainless steel tubes,TP304 stainless steel tubes,SA312 304L stainless pipes


    Product Tags:

    TP304 Stainless Steel Tubing



    Mirror Polished Stainless Steel Tubing


    Quality Boiler TP304 Mirror Polished Stainless Steel Tubing for sale

    Boiler TP304 Mirror Polished Stainless Steel Tubing
