    ASTM A789 A789M Seamless Boiler Tube Ferritic Austenitic Stainless Steel Tubing S32760 S31803 S32750 S31500

    Ask Lasest Price
    Brand Name : New Era
    Model Number : ASTM A200
    Certification : ISO9001
    Price : Negotiation
    Payment Terms : T/T
    Supply Ability : 3000 tons/month
    Delivery Time : 45 days
    • Product Details
    • Company Profile

    ASTM A789 A789M Seamless Boiler Tube Ferritic Austenitic Stainless Steel Tubing S32760 S31803 S32750 S31500

    25.4x1.65mm 19.05x1.65mmS32760 S31803 S32750 S31500 ASTM A789 A789M Seamless Ferritic Austenitic Stainless Steel Tubing


    1. Scope

    This specification covers grades of nominal wall thickness, stainless steel tubing for services requiring general corrosion resistance, with particular emphasis on resistance to stress corrosion cracking. These steels are susceptible to embrittlement if used for prolonged periods at elevated temperatures.

    The values stated in either SI units or inch-pound units are to be regarded separately as standard. The values stated in each system may not be exact equivalents; therefore, each system shall be used independently of the other. Combining values from the two systems may result in non-conformance with the standard. Within the text, the SI units are shown in brackets. The inch-pound units shall apply unless the M designation of this specification is specified in the order.

    Keywords:Corrosive Service Applications - Duplex And Super Duplex Stainless Steel - Seamless Pipes And Tubes - Stress Corrosion Cracking - Welded Pipes And Tubes
    Size Range: OD: 6-89mm, WT: 1-8mm, Length: 5.8m/6m, maximal 11.8m
    Stable Quality with Comeptitive Price
    High Performance and Longer Working Life Steel Pipe

    Application: ASTM A789/SA789M Ferritic/Austenitic Stainless Steel Tubing for General Service
    100% Eddy Current Testing/Hydraulic Testing
    100% Size Tolerance Checking.
    100% Tube surface checking to avoid surface defects.


    Product NameFerritic Austenitic Stainless Steel Tubing,heater tubes
    MaterialS32900 S31803 S32205 S32750 S32760 S31500
    StandardASTM A789/SA789M
    ApplicationBoiler Pressure steel tubes
    CertificateISO 9001
    HS code7304319000
    Delivery Time45 days
    PakcingBundles or Woodern Boxes

    UNSBCMnPSSiNiCrMoNCuOther
    S329000.0801.000.0400.0300.7502.5～5.023.0～28.01.00～2.00………
    S318030.0302.000.0300.0201.004.5～6.521.0～23.02.50～3.500.08～0.20……
    S322050.0302.000.0300.0201.004.5～6.522.0～23.03.00～3.500.14～0.20……
    S327500.0301.200.0350.0200.806.0～8.024.0～26.03.00～5.000.24～0.320.50…
    S315000.0301.20～2.000.0300.0301.4～2.04.50～5.2518.0～19.02.50～3.000.05～0.10……

    UNSTemperature℉(℃)Heat-treatmentTensile Min ksi,(MPa)Yield Min ksi,(MPa)

    Elongation 2inor 50mm,

    %A B

    		Max Hardness
    HBWHRC
    S329001700～1750℉(925～955℃)Cooling in air or water90(620)70(485)2027128
    S318031870～2010℉(1020～1100℃)Cooling in air or water90(620)65(450)2529030.5
    S322051870～2010℉(1020～1100℃)Cooling in air or water95(655)70(485)2529030.5
    S327501880～2060℉(1025～1125℃)Cooling in air or water116(800)80(550)1531032
    S315001800～1900℉(980～1040℃)Cooling in air or water92(630)64(440)3029030.5

    High pressure, low & medium pressure boiler steel pipestubes are suitable for making
    super-heaters, re-heaters, water wall, and economizer in large-scale power plant.

    Flattening Test – One flattening test shall be made on specimens from each end of one finished tube, not the one used for the flaring test, from each lot.
    Flaring Test – One flaring test shall be made on specimens from each end of one finished tube, not the one used for the flattening test, from each lot.
    Hydrostatic or Nondestructive Electric Test – Each tube shall be subjected to the nondestructive electric test or the hydrostatic test. The type of test to be used shall be at the option of the manufacturer, unless otherwise specified in the purchase order.
    Materials and Manufacture:
    The Steel shall be killed.
    The Tubes shall be made by the seamless process and shall be either hot-finished or cold finished, as specified.
    Heat Treatment – Ferritic Alloy and Ferritic Stainless Steels – The ferritic alloy and ferritic stainless steels shall be reheated for heat treatment in accordance with the requirements of Standard. Heat treatment shall be carried out separately and in addition to heating for hot forming.


    ASTM A789 A789M Seamless Boiler Tube Ferritic Austenitic Stainless Steel Tubing S32760 S31803 S32750 S31500
    ASTM A789 A789M Seamless Boiler Tube Ferritic Austenitic Stainless Steel Tubing S32760 S31803 S32750 S31500
    ASTM A789 A789M Seamless Boiler Tube Ferritic Austenitic Stainless Steel Tubing S32760 S31803 S32750 S31500

    FAQ:

    1. Can you provide a sample to check the quality?
    We can provide free sample with same or similar sizes for you to check tube quality.
    You need to in charge of Express costs.

    2. How about your production capacity?
    3000 tons/Month.

    3. What are your terms of payment?
    30%TT in advance, Balance to be paid before shipment.

    4. Where is your factory?
    Jiaxing city, 2 hours away from Shanghai.

    5. How can I get the quotation A.S.A.P?
    Please send us an inquiry with full details as following,quotation will sent to you A.S.A.P:
    1). Tube Standard
    2). Steel Grade
    3). Tube Size and Size Tolerance
    4). Tube length
    5). Quantity
    6). If any special requirements

    6. How about the minimum order quantity?
    Normally for one size above 1 ton.
