Round 2 Inch Polished Stainless Steel Pipe For Heat Exchangers / Condensers

Ask Lasest Price
Brand Name :	New-Era
Model Number :	ASTM A213
Certification :	GB/T 19001-2008 , ISO 9001:2008 , TS16949
Price :	Negotiation
Payment Terms :	T/T
Supply Ability :	500tons per month
Delivery Time :	35-45days

Add to Cart

Product Details
Company Profile

Round 2 Inch Polished Stainless Steel Pipe For Heat Exchangers / Condensers

2 inch stainless steel tubing for Heat Exchangers / Condensers 304 316

Grade: UNS N02200, UNS N02201

Production: Cold worked, Hot worked

Size range: O.D.:6-127mm W.T.:1-30mm L: according to Customer requirement

TABLE 2 Chemical Requirements
Chemical Compostion	Composition, %
Element	Nicel (UNS N02200)	Low-Carbon Nickel (UNS N02201)
Ni,A min	99.00	99.00
Cu	0.25	0.25
Fe	0.40	0.40
Mn, max	0.35	0.35
C,max	0.15	0.02
Si,max	0.35	0.35
S,max	0.01	0.01

Delivery Conditions:

Symbols	Types of delivery condition	Surface Condition
HFD	Hot finished heat treated, descaled	Metallically clean
CFD	Cold finished heat treated, descaled	Metallically clean
CFA	Cold finished bright annealed	Metallically bright
CFG	Cold finished heat treated, ground	Metallically bright-ground, the type and degree of roughness shall be agreed at the time of enquiry and order
CFP	Cold finished heat treated, polished	Metallically bright-polished, the type and degree of roughness shall be agreed at the time of enquiry and order
a Combinations of the different conditions may be agreed at the time of enquiry and order b The symbols are abbreviation for type of condition. Example: CDF = Cold Finished Descaled c The enquiry and the order shall indicate whether the roughness requirement applies on the internal or external tube surface, or internal and external

Type one: Pickling Pipe

Size: OD:0.23''-80''(5.8-2032mm)

WT:0.01''-1.125''(0.25-28mm)

ANSI/ASME size as under,

NPS:1/8''-80'' SCH:5/5s,10/10s,20/20s,40/40s,80/80s,120/120s,160/160s acc. to ANSI B36.19/36.10

other standard of size is for ready choice.

Length: according to clients' request.

Standard:JIS DIN GB BS ASTM(ASME) etc.

Surface Finish: Annealed,Polish,Brush etc.

Application:for fluid and gas transport structure and machining.

Packing:Plywood cases or bundles.

Type two: Bright Annealed Tube

Size: OD range:6-50.8mm WT range:0.71-3.68mm Length:6-24m

Standard:ASTM A249, EN 10217-7, etc

Process Method:Welded ,bright annealed.

Surface Finish:Bright Annealed(BA),pickling,bright annealed(BA)&polish

Packing:Plywood cases or bundles.

Applications: Steel tubes for Heat Exchangers and Condensers

Round 2 Inch Polished Stainless Steel Pipe For Heat Exchangers / Condensers
