Carbon Steel Seamless Cold Drawn Steel Tube For Hydraulic / Pneumatic Power Systems

Ask Lasest Price
Brand Name :	New Era
Model Number :	EN10305-4
Certification :	ISO 9001 ISO14001 TS 16949
Price :	Negotiation
Payment Terms :	T/T
Supply Ability :	5000 tons/month
Delivery Time :	45 days

Add to Cart

Product Details
Company Profile

Carbon Steel Seamless Cold Drawn Steel Tube For Hydraulic / Pneumatic Power Systems

**EN10305-4 E235 +N Carbon Steel Seamless Precision Hydraulic Tube,61.0,81.5,101.5,161.5,25*3.0**

1. Standard:
EN10305-4 Cold drawn Precision Seamless Steel Pipes

2. Steel Grade:
E215,E235,E355, other materials upon agreement with customers.

3. Production method:
Cold drawing on the seamless steel tubes, to reach high accuracy on the OD and WT tolerance,
with certain heat treatment to achieve better mechanical properties for bending and pressure purposes

4. Size range:
O.D.:5-100mm W.T.:1-15mm L:max12000mm

5. Packing:
In Hexagonal Bundles, with anti-rust oil protection, with seaworthy packing

6. Deliver condition:
+NAfter the final cold drawing operation the tubes are normalized in a controlled atmosphere
Please specify the final heat treatment when sending the enquiry.

7. Inspection and testing:
Chemical analysis
Tensile test
Flattening test or Drift expanding test
Dimensional inspection
Visual examination
NDT for verification of leaking tightness

Steel Grade		C	Si	Mn	P	S	Al
Steel Name	Steel Number	max	max	max	max	max	min
E215	1.0212	0.10	0.05	0.70	0.025	0.025	0.025
E235	1.0308	0.17	0.35	1.20	0.025	0.025	-
E355	1.0580	0.22	0.55	1.60	0.025	0.025
