ASTM A513 DOM1026 Thin Wall Steel Tubing

Ask Lasest Price
Brand Name :	New Era
Model Number :	ASTM A513
Certification :	ISO9001, ISO14001, TS16949
Price :	Negotiation
Payment Terms :	T/T
Supply Ability :	500 tons/month
Delivery Time :	45 days

Add to Cart

Product Details
Company Profile

ASTM A513 DOM1026 Thin Wall Steel Tubing

Products Description

High Tensile Thin Wall 34mm MS 1010 Plastic End Caps for AISI 1020 46mm 4130 Carbon Seamless Mild ASTM A513 1026 DOM Tube

Quick Detail:

Honed steel pipes is used for hydraulic Cylinders and oil and pnuematic Cylinders.with material E155 E195 E235 E275 E355. Raw material steel pipes as per stamdard EN10305-2, Cold drawn ERW steel pipes , Cold drawn seamless pipes.

Feature
1.Honed Hydraulic Cylinder Tube is made from DOM steel tubes,With high precison .
2.Low costs than seamless honed hydraulic cylinder tubes.
3.DOM steel tubes ID machining by method Honing, Skiving, Roller Burnish.Improve ID surface .will have Good performace on end product.
4.Steel tubes with heat treatment , will be in nice mechanical properties .

Detail info:

Product name	EN10305-2 DOM Honed Hydraulic Cylinder Tube
Grade	carbon steel E155, E195, E235, E275, E355. S45C
Size	ID.: 20-450mm W.T.:1-80mm L:max12000mm
Standard	EN10305-2
Certification	ISO9001, TS16949
Used	for Auto industry for machinery use Oil Cylinder Tube Motorcyle shock absorber Auto shock absorber innder cylinder Telescopic Cylinders
Heat treatment method	+Cc, +LCc, +SR, +Ad, +N Note: Special steel grade is also available, according to customer request. Please specify the steel grade and heat treatment mothod when sending the enquiry!

Others:
Test Methods:
Tensile test
Flattening test
Drift expanding test
Dimensional inspection
Roughness measurement
Visual examincation
Not-destructive testing
a. Test for longitudinal imperfections-
- Eddy current test - EN10246-3, level E3
- ultrasonic testing - EN10246-7, level U3
b. Leak-tightness
- Non-destructive testing for verification of leak-tightness shall be carried out in accordance with EN10246-1

EN10305 Consists of the following Parts under the general title " Steel tubes for precision applications - Technical delivery conditions "
Part 1: Seamless Cold Drawn Tubes
Part 2: Welded Cold Drawn Tubes
Part 3: Welded Cold Sized Tubes
Part 4: Seamless Cold Drawn Tubes for Hydraulic and Pneumatic Power Systems
Part 5: Welded and Cold Sized Square and Rectangular Tubes
Part 6: Welded Cold Drawn Tubes for Hydraulic and Pneumatic Power Systems

ASTM A513 DOM1026 Thin Wall Steel Tubing
