Small OD Precision Dom Steel Tubing ASTM / A513 Type With Clean Surface

Ask Lasest Price
Brand Name :	New Era
Model Number :	ASTM A513 Type5
Certification :	ISO9001,TS16949
Price :	Negotiation
Payment Terms :	T/T
Supply Ability :	3000 tons/month
Delivery Time :	45 days

Add to Cart

Product Details
Company Profile

Small OD Precision Dom Steel Tubing ASTM / A513 Type With Clean Surface

Product Name: Small OD Precision DOM Steel Tubing ASTM A513 Type5 1020 1026 4130 with Clean surface
Application: For auto parts, machinery, mechanical engineer
Size(mm): O. D.: 6.0-168.0 W. T.: 1.0-15.0mm L: Max 12000mm

DOM mechanical tubing is manufactured to ASTM Specification A513

This product has tensile properties that are comparable to cold-drawn seamless steel tubing of the same steel analysis and nominal size. In addition, the DOM tubing has superior concentricity and a high degree of uniformity in wall thickness.

High Quality and Competitive Price. Welcome to contact us.

Steel Grade	C Max	Mn	P Max	S Max	Si Max	Cr Max	Mo
1008	0.10	0.30-0.50	0.035	0.035	-	-	-
1010	0.08-0.13	0.30-0.60	0.035	0.035	-	-	-
1018	0.14-0.20	0.60-0.90	0.035	0.035	-	-	-
1020	0.18-0.23	0.30-0.60	0.035	0.035	-	-	-
1026	0.22-0.28	0.60-0.90	0.035	0.035	-	-	-
1035	0.32-0.38	0.60-0.90	0.035	0.035	-	-	-
1045	0.37-0.44	0.60-0.90	0.035	0.035	-	-	-
4130	0.28-0.33	0.40-0.60	0.035	0.035	0.15-0.35	0.80-1.10	0.15-0.25
4140	0.38-0.43	0.75-1.00	0.035	0.035	0.15-0.35	0.80-1.10	0.15-0.25

Mechanical Properties:

Steel Grade	Yield Strength		Tensile Strength		Elongation	RB	RB
Steel Grade	Ksi	Mpa	ksi	Mpa	%	min	max
Sink-Drawn Tubing
1008	38	262	48	331	8	65
1010	40	276	50	345	8	65
1020	50	345	60	414	8	70
1026	55	379	70	483	7	77
1035	70	483	80	552	7	82
4130	50	345	70	483	20	100
4140	65	448	90	621	20	105

Steel Grade	Yield Strength		Tensile Strength		Elongation	RB	RB
Steel Grade	Ksi	Mpa	ksi	Mpa	%	min	max
Normalizing Tubing
1008	23	159	38	262		30	65
1010	25	172	40	276		30	65
1020	35	241	50	345		25	75
1026	40	276	60	414		25	80
1035	45	310	65	448		20	85

Steel Grade	Yield Strength			Tensile Strength		Elongation	RB	RB
Steel Grade	Ksi	Mpa		ksi	Mpa	%	min	max
Mandrel-DrawnStress-Relieved Tubing
1008	45		310	55	379	12		68
1010	45		310	55	379	12		68
1020	55		379	65	448	10		75
1026	65		448	75	517	10		80
1035	75		517	85	586	10		85
4130	80		552	90	621	10		87
4140	95		655	105	724	10		90
