Super length ASTM A249 SUS304 SUS316 Stainless Seamless Boiler Tube

Materials SUS304 SUS316 TP304 TP316

Material	Stainless Steel SUS304/304L/316L
Shape	Round / Square / Rectangle
Production Standards	ASTM A270, ASTM A269, ASTM A249, ASTM A778, ASTM A789, DIN 11850, EN 10357, EN 10217-7 and so on.
Production Standards
Outer Diameter	16mm -300mm ;
Thickness	0.8mm - 20 mm ;
Length	6 Meters - 18.3 Meters ; As customers' request ;
Tolerance	According to the Standard , +/-10% Commonly ;
Surface Treatment	180#, 320#, 400# Satin / Hairline, Bright Anneal, Pickle,400#, 500#, 600# or 800# Mirror finish
Application	Petrochemical Industry ; Chemical Fertilizer Industry ; Oil Refining Industry ; Oil And Gas Industry ; Light Industry And Food Industry ; Pulp And Paper Industry ; Energy And Environmental Industries .
Test	Flaring test ; Flattening test ; Bending Test ; Hydraulic Test ; Eddy Current test
Design	OEM / ODM / Customized
Certificate	ISO9001 ; ISO14001; ISO 18001; TUV ;

Stainless Steel Mechanical Properties
Grade		Tensile Strength	Yide Strength	Elogation	Hardness	Solution Annealing
Grade		kgf/mm²(N/mm²)	kgf/mm²(N/mm²)	%	HRB(HV)	ºC
ASTM	TP 304	≥53 (515)	≥21 (205)	≥35	≤90 (200)	1040ºC-1150ºC Water Quenching
	TP 304L	≥50 (485)	≥17 (170)
	TP 316	≥53 (515)	≥21 (205)
	TP 316L	≥50 (485)	≥17 (170)
JIS	SUS 304	≥53 (520)	≥21 (205)			1010ºC-1150ºC Water Quenching
	SUS 304L	≥49 (480)	≥18 (175)
	SUS 316	≥53 (520)	≥21 (205)
	SUS 316L	≥49 (480)	≥18 (175)
GB	06Cr19Ni10	≥53 (520)	≥21 (210)			1010ºC-1150ºC Water Quenching
	022Cr19Ni10	≥49 (480)	≥18 (180)
	06Cr17Ni12Mo2	≥53 (520)	≥21 (210)
	022Cr17Ni12Mo2	≥59 (480)	≥18 (180)
EN	1.4301	(500-700)	≥20 (195)	≥40		1000ºC-1100ºC Water Quenching
	1.4307	(470-670)	≥18 (180)			1000ºC-1100ºC Water Quenching
	1.4401	(510-710)	≥21 (205)			1020ºC-1120ºC Water Quenching
	1.4404	(490-690)	≥19 (195)			1020ºC-1120ºC Water Quenching

Stainless Steel Heat Exchanger Tube
Standard	OD(mm)	WT(mm)	Length(meters)	Grade
ASTM A249, ASTM A269, EN 10217-7	15.88 to 114.3	0.3 to 4.0	Up to 18.3 meter	1.4301, 1.4306, 1.4404, AISI 304/304l/316l, S31803/S32205, etc
Standard	Outside Diameter		Thickness	Length
ASTM A249 (A1016)	<25.4	±0.10	±10%S	OD<50.8+3-0 OD≥50.8+5-0
	≥25.4~<38.1	±0.15
	≥38.1~<50.8	±0.20
	≥50.8~<63.5	±0.25
	≥63.5~<76.2	±0.31
ASTM A269 (A1016)	<38.1	±0.13	OD<12.7±15% OD≥12.7±10%	OD<38.1+3.2-0 OD≥38.1+4.8-0
	≥38.1~<88.9	±0.25
	≥88.9~<139.7	±0.38
